How to Manage ‘Systemd’ Services and Units Using ‘Systemctl’ in Linux

CPU Utilization (Shares) of a Service

25. Get the current CPU Shares of a Service (say httpd).

# systemctl show -p CPUShares httpd.service

CPUShares=1024

Note: The default each service has a CPUShare = 1024. You may increase/decrease CPU share of a process.

26. Limit the CPU Share of a service (httpd.service) to 2000 CPUShares/

# systemctl set-property httpd.service CPUShares=2000
# systemctl show -p CPUShares httpd.service

CPUShares=2000

Note: When you set CPUShare for a service, a directory with the name of service is created (httpd.service.d) which contains a file 90-CPUShares.conf which contains the CPUShare Limit information. You may view the file as:

# vi /etc/systemd/system/httpd.service.d/90-CPUShares.conf

[Service]
CPUShares=2000

27. Check all the configuration details of a service.

# systemctl show httpd

Id=httpd.service
Names=httpd.service
Requires=basic.target
Wants=system.slice
WantedBy=multi-user.target
Conflicts=shutdown.target
Before=shutdown.target multi-user.target
After=network.target remote-fs.target nss-lookup.target systemd-journald.socket basic.target system.slice
Description=The Apache HTTP Server
LoadState=loaded
ActiveState=active
SubState=running
FragmentPath=/usr/lib/systemd/system/httpd.service
....

28. Analyze critical chain for a services(httpd).

# systemd-analyze critical-chain httpd.service

The time after the unit is active or started is printed after the "@" character.
The time the unit takes to start is printed after the "+" character.

httpd.service +142ms
└─network.target @11.168s
  └─network.service @9.456s +1.712s
    └─NetworkManager.service @8.858s +596ms
      └─firewalld.service @4.931s +3.926s
        └─basic.target @4.916s
          └─sockets.target @4.916s
            └─dbus.socket @4.916s
              └─sysinit.target @4.905s
                └─systemd-update-utmp.service @4.864s +39ms
                  └─auditd.service @4.563s +301ms
                    └─systemd-tmpfiles-setup.service @4.485s +69ms
                      └─rhel-import-state.service @4.342s +142ms
                        └─local-fs.target @4.324s
                          └─boot.mount @4.286s +31ms
                            └─[email protected]\x2duuid-79f594ad\x2da332\x2d4730\x2dbb5f\x2d85d196080964.service @4.092s +149ms
                              └─dev-disk-by\x2duuid-79f594ad\x2da332\x2d4730\x2dbb5f\x2d85d196080964.device @4.092s

29. Get a list of dependencies for a services (httpd).

# systemctl list-dependencies httpd.service

httpd.service
├─system.slice
└─basic.target
  ├─firewalld.service
  ├─microcode.service
  ├─rhel-autorelabel-mark.service
  ├─rhel-autorelabel.service
  ├─rhel-configure.service
  ├─rhel-dmesg.service
  ├─rhel-loadmodules.service
  ├─paths.target
  ├─slices.target
  │ ├─-.slice
  │ └─system.slice
  ├─sockets.target
  │ ├─dbus.socket
....

30. List control groups hierarchically.

# systemd-cgls

├─1 /usr/lib/systemd/systemd --switched-root --system --deserialize 23
├─user.slice
│ └─user-0.slice
│   └─session-1.scope
│     ├─2498 sshd: [email protected]/0
│     ├─2500 -bash
│     ├─4521 systemd-cgls
│     └─4522 systemd-cgls
└─system.slice
  ├─httpd.service
  │ ├─4440 /usr/sbin/httpd -DFOREGROUND
  │ ├─4442 /usr/sbin/httpd -DFOREGROUND
  │ ├─4443 /usr/sbin/httpd -DFOREGROUND
  │ ├─4444 /usr/sbin/httpd -DFOREGROUND
  │ ├─4445 /usr/sbin/httpd -DFOREGROUND
  │ └─4446 /usr/sbin/httpd -DFOREGROUND
  ├─polkit.service
  │ └─721 /usr/lib/polkit-1/polkitd --no-debug
....

31. List control group according to CPU, memory, Input and Output.

# systemd-cgtop

Path                                                              Tasks   %CPU   Memory  Input/s Output/s

/                                                                    83    1.0   437.8M        -        -
/system.slice                                                         -    0.1        -        -        -
/system.slice/mariadb.service                                         2    0.1        -        -        -
/system.slice/tuned.service                                           1    0.0        -        -        -
/system.slice/httpd.service                                           6    0.0        -        -        -
/system.slice/NetworkManager.service                                  1      -        -        -        -
/system.slice/atop.service                                            1      -        -        -        -
/system.slice/atopacct.service                                        1      -        -        -        -
/system.slice/auditd.service                                          1      -        -        -        -
/system.slice/crond.service                                           1      -        -        -        -
/system.slice/dbus.service                                            1      -        -        -        -
/system.slice/firewalld.service                                       1      -        -        -        -
/system.slice/lvm2-lvmetad.service                                    1      -        -        -        -
/system.slice/polkit.service                                          1      -        -        -        -
/system.slice/postfix.service                                         3      -        -        -        -
/system.slice/rsyslog.service                                         1      -        -        -        -
/system.slice/system-getty.slice/[email protected]                   1      -        -        -        -
/system.slice/systemd-journald.service                                1      -        -        -        -
/system.slice/systemd-logind.service                                  1      -        -        -        -
/system.slice/systemd-udevd.service                                   1      -        -        -        -
/system.slice/webmin.service                                          1      -        -        -        -
/user.slice/user-0.slice/session-1.scope                              3      -        -        -        -

Control System Runlevels

32. How to start system rescue mode.

# systemctl rescue

Broadcast message from [email protected] on pts/0 (Wed 2015-04-29 11:31:18 IST):

The system is going down to rescue mode NOW!

33. How to enter into emergency mode.

# systemctl emergency

Welcome to emergency mode! After logging in, type "journalctl -xb" to view
system logs, "systemctl reboot" to reboot, "systemctl default" to try again
to boot into default mode.

34. List current run levels in use.

# systemctl get-default

multi-user.target

35. How to start Runlevel 5 aka graphical mode.

# systemctl isolate runlevel5.target
OR
# systemctl isolate graphical.target

36. How to start Runlevel 3 aka multiuser mode (commandline).

# systemctl isolate runlevel3.target
OR
# systemctl isolate multiuser.target

36. How to set multiusermode or graphical mode as default runlevel.

# systemctl set-default runlevel3.target

# systemctl set-default runlevel5.target

37. How to reboot, halt, suspend, hibernate or put system in hybrid-sleep.

# systemctl reboot

# systemctl halt

# systemctl suspend

# systemctl hibernate

# systemctl hybrid-sleep

For those who may not be aware of runlevels and what it does.

  1. Runlevel 0 : Shut down and Power off the system.
  2. Runlevel 1 : Rescue?Maintainance Mode.
  3. Runlevel 3 : multiuser, no-graphic system.
  4. Runlevel 4 : multiuser, no-graphic system.
  5. Runlevel 5 : multiuser, graphical system.
  6. Runlevel 6 : Shutdown and Reboot the machine.

That’s all for now. Keep connected! Keep commenting. Don’t forget to provide us with your valuable feedback in the comments below. Like and share us and help us get spread.
